gate 7
gate 7 is an iris recognition access control, with body temperature detection, which also support rfid card reading. its 2.2″ oled display makes this device very user-friendly.
it can work in standalone mode, or in ethernet. 10,000 users. 50,000 logs.
applications：office buildings, apartment buildings, bank, hospital, government facilities, prison, ports, stadiums, electric power facilities, and other high security required locations.
specification
iris recognition
| work mode | standalone,tcp/ip | size | 51 x 122 x 24.5cm |
| identification mode | monocular, dual iris | iris image | conform to iso/iec 19794-6: 2005 |
| auto capture | yes | illumination | conform to iec/en 62471 safety standard |
| enrollment speed | <1s | rfid | ic card |
| identification speed | <0.5s | interface | rj45, rs485, rs232, wiegand 26/34 output, 1 relay output, open door switch |
| accuracy | far<0.00001%, frr<1% | case material | abs |
| working distance | 30-65cm | weight | 300g |
| working temperature | -20～60℃ | power consumption | <12w |
| ambient brightness | 0-10000lux | power | dc12v |
| distance notice | screen display | accessory | wall mounting plate |
temperature
| accuracy | 0.02℃ | environment temperature | -40～125℃ |
| measurement deviation (body temperature) | /-0.3℃ | measuring distance | 30～65cm |
| body temperature range | 28-43℃ | ||
